- Collimator Rotary:360°
- Camerra:CCD
- Resolution:1280 x 1024(12 bit)
- LCD Display:21"LCD display with digital workstation
- C-arm open distance:740mm
- SID:960mm
- Arch depth:640mm
- Backward and Forward:200 mm
- Vertical:400 mm (motorized )
- orbital rotation:120°(-30°-+90°)
- Properties:Medical X-ray Equipments & Accessories
- Instrument classification:Class II
- Warranty:1 Year
- After-sale Service:Online technical support
- Place of Origin:CN;GUA
- Brand Name:MAYA
- Model Number:MY-D035B
"Anode Type""Fixed anode
Focal: 0.3/1.5mm""
Anode Thermal capacity 35kJ(47kHu)
Tube assembly thermal capacity 650kJ(867kHu)
Generator
Output Power 5kW
Frequency 40kHz
Tube Current 40 - 120 KV
Fluoroscopy mode""Continuous fluoroscopy:
0.3mA~~4mA;
Pulse fluoroscopy:
0.3mA~~30mA;
IBS available"
Radiography""Radiography:
20-100mA/180mAs""
Image Intensifier Toshiba
Filed viewing 9""Single filed
Iris Collimator yes
Collimator Rotary 360°
Camerra CCD
Resolution 1280 x 1024(12bit)
LCD Display 21""LCD display with digital workstation
Mechanical structure
C-arm open distance 740mm
SID 960mm
Arch depth 640mm
Movement
Isocenter /
Counterbalance yes
Backward and Forward 200 mm
Vertical 400 mm (motorized )
horizontal axis ratory +-180°
orbital rotation 120°(-30°-+90°)
Revolution around vertical axis +-15°
