MY-D054 Hospital Medical 0.5T MRI scanner/scan/machine equipment price for sale
MY-D054 Hospital Medical 0.5T MRI scanner/scan/machine equipment price for sale
MY-D054 Hospital Medical 0.5T MRI scanner/scan/machine equipment price for sale
MY-D054 Hospital Medical 0.5T MRI scanner/scan/machine equipment price for sale
MY-D054 Hospital Medical 0.5T MRI scanner/scan/machine equipment price for sale

MY-D054 Hospital Medical 0.5T MRI scanner/scan/machine equipment price for sale

USD200,000.00 -USD690,000.00
  • Delivery:FOB
  • Minimum order quantity:1 set
  • Supply Ability:100 set / Month
  • Country of Origin:Guangzhou
  • Categories: CT MRI
    Model NO.: MY-D054
    • Place of Origin:CN;GUA
    • Instrument classification:Class II
    • Properties:CT
    • Brand Name:MAYA
    • Model Number:MY-D054
    • Product name:0.5T MRI machine
    • Certificate:CE ISO
    Product Description

    MY-D054 Hospital Medical 0.5T MRI scanner/scan/machine equipment price for sale

    D054 0.5T.jpg

    1. Excellent price performance ratio

    Comprehensive application suite and powerful software included in standard configuration

    2. Patient friendly appearance

    Full open C-shaped magnet

    3. Minimal sitting requirements

    Less than 56 m² ;

    4. Low operating Costs

    Permanent magnet – no helium

    5. Higher revenues

    Attracted by more patients and referring physicians

    6. Excellent Return On Investment

    Decreased costs-optimized profitability

    7. Efficient and Professional service team

    24 hours service on-line

    Next pages- detailed specifications

    Specifications of 0.5T System

    1.0 Magnet:

    Operating Field Strength 0.50 Tesla 5000 Gauss

    Magnet Type Open design permanent, eddy current free, self-constant temperature

    Magnetic material Permanent Nd-Fe-B magnet

    Dimension 2000x2200x2100mm

    Net Weight 27,000KG

    Homogeneity (400mm DSV) ≤ 2.5ppm (Vrms)

    Shimming Passive shimming or active shimming

    Patient aperture 400mm

    2.0 Gradient System:

    Gradient strengh max. 25mT/m (Gx/Gy/Gz)

    Slew rate 75mT/M/ms (Gx/Gy/Gz)

    Gradient lNon-linearity <5%(400mm×400mm×380mm)

    3.0 RF System:

    Central frequency DC~400MHz

    Spectrometer Digital (Four channels)

    Transmitting coil Flat planar coil

    Receiving coils Phase array coil (Neck coil, Head coil, Large body coil, Small body coil, knee coil)

    Optional coils Wrist coil, Shoulder coil , spine coil, breast coil, ankle coil, etc.

    Max. receiver bandwidth 1.25Mhz

    Power of transmitter amplifier 6KW

    4.0 Computer System:

    Operating system Windows2000/NT/XP

    CPU 2.8GHz(Dual Core Processor)

    Hard disk ≥250GB

    RAM 2048MB (2GB)

    Display Device ≥22’’ TFT

    Network & laser printer interface DICOM3.0

    Software 0.5T Software

    5.0 Auto Pre- scan

    6.0 Pulse Sequence:

    Standard IR

    Spin Echo ( SE 2D/3D)

    Multi-slice multi-echo (MSME)

    Gradient Echo (GRE 2D/3D)

    Steady state process gradient echo( SSPGRE)

    Fast spin echo (FSE)

    Single shot fast spin echo(SSFSE)

    Multi shot fast spin echo (MSFSE)

    Inversion recovery (IR)

    Inversion recovery fast spin echo (IRFSE)

    Short time inversion recovery (STIR)

    Fluid attenuated inversion recovery ( FLAIR)

    MRM, MRU, MRCP

    TOF 2D/3D MRA

    Diffusion weighted imaging (DWI)

    Echo planar imaging(EPI)

    7.0 Scanning Parameter:

    Acquisition matrix 64/128/256/512

    Resolution 1mm(head 24cm FOV 256X256)

    1.5MM(body 30cm FOV 256X256)

    0.5mm(head 24cm FOV 512X512)

    0.75mm( body 30cm FOV 512X512)

    Maximum display matrix 1024x1024

    FOV 20 ~ 400mm

    Slide thickness (2D)Min.1mm(1mm increment), (3D)Min. 0.5mm

    Slide Orientation Sagittal, coronal, transversal, any angle any oblique

    Image Type:

    T1 Weighted imaging , T2 weighted imaging ,T2* weighted imaging , proton density imaging;Water Suppressed Imange,Fat Suppressed Image, MRM, MRU,MRCP; Magnetic Resonance angiography (MRA), Diffusion Weighted Imaging (DWI)

    8.0 Patient Table:

    Max. Patient load about 240kg;

    Available with laser light localizer for patient positioning

    Longitudinal travel range: ≥1650mm

    Intercommunication between patient and operator: available

    9.0 Power Supply

    3N---380V 50Hz 15KVA

    10.0 Typical Layout:

    Magnet Room About 36 Square meters(6m×6m);

    Equipment Room About 16 Square meters(4m×4m);

    Control Room About 4 Square meters(2m×2m);

    Total MRI-System area About 56 Square meters.

    D054 0.5t-3.jpgD054 0-5-4.jpg
