working modes pure cut or cut 5~300W(may provide type 5~400W)
blend 1 5~240W
blend 2 5~200W
blend 3 5~150W
desiccate 5~200W
fulgurate or coag. 5~150W
spray 5~100W
bipolar 2~70W
range of use May use to various surgical operations of cutting or/and coagulation to organism tissue.
disposation of accessaries active electrode 5
footswitch 1
neutral electrode 1
bipolar electrode 1
disposable electrode pick out and buy
transport data package dimensions 45×26.5×47cm
gross weight 12kg
technology data voltage of mains 220V ±22V,50Hz/60Hz
working freguency 512kHz ±5Hz
variety of equipment class 1,type CF.ordinary eguipment
working fashion loading intermittently,functioning continuously.
leskage currents to ground less than 0.5mA
leskage currents through patient less than 0.01mA
Packing Size 450*265*470mm
N.W/ G.W 10KG /12KG
